Procesor Phenom quad core AM2+ AM3

Family
AMD Phenom X4
Model number ? 9500
CPU part numbers
HD9500WCJ4BGD
Frequency 2200 MHz
Bus speed One 1800 MHz 16-bit HyperTransport link (3.6 GT/s)
Clock multiplier 11
Package 940-pin organic micro-PGA
Sockets Socket AM2
Socket AM2+
Microarchitecture K10
Platform Cartwheel (mainstream platform with AMD 780G chipset)
Spider (performance platform with AMD 790FX/790GX chipsets)
Data width 64 bit
The number of CPU cores 4
The number of threads 4
Level 1 cache size 4 x 64 KB 2-way set associative instruction caches
4 x 64 KB 2-way set associative data caches
Level 2 cache size 4 x 512 KB 16-way set associative caches
Level 3 cache size 2 MB 32-way set associative shared cache
Extensions to MMX
3DNow! technolog
Memory channels: 2
Channel width (bits): 72
Supported memory: DDR2-1066
DIMMs per channel: up to 2
Maximum memory bandwidth (GB/s): 17.1
Maximum operating temperature 55°C - 70°C
Thermal Design Power ? 95 Watt
100L

Procesor Phenom II
Family
AMD Phenom II X2
Model number 550
HDX550WFK2DGM
Frequency 3100 MHz
Bus speed 667 MHz Memory controller
One 2000 MHz 16-bit HyperTransport link (4 GT/s)
Clock multiplier 15.5
Package 938-pin organic micro-PGA
Sockets Socket AM2+/Socket AM3
The number of CPU cores 2
The number of threads 2
100L

procesor phenom II x4
ADX640WFK42GM
Frequency 3000 MHz
Bus speed 667 MHz Memory controller
One 2000 MHz 16-bit HyperTransport link
Clock multiplier ? 15
Package 938-pin organic micro-PGA
Sockets Socket AM2+
Socket AM3
The number of CPU cores 4
The number of threads 4
150L

procesor phenom II x6
HDT45TWFK6DGR
Frequency 2700 MHz
Maximum turbo frequency 3200 MHz (3 cores or less)
Bus speed 667 MHz Memory controller
One 2000 MHz 16-bit HyperTransport link (4 GT/s)
Clock multiplier 13.5
Package 938-pin organic micro-PGA
Socket Socket AM3
The number of CPU cores 6
The number of threads 6
250L

Family
AMD FX-Series
Model number FX-6100
Frequency 3300 MHz
Maximum turbo frequency 3600 MHz (more than 3 cores)
3900 MHz (3 cores or less)
Bus speed One 2600 MHz 16-bit HyperTransport link
Package 940-pin organic micro Pin Grid Array (UOC940)
Pb-free
Socket Socket AM3+
Microarchitecture Bulldozer
Platform Scorpius
Processor core Zambezi
Core stepping OR-B2
CPUID 600F12
Manufacturing process 0.032 micron Hi-K Metal Gate process with silicon-on-insulator (SOI) technology
Die 316mm2
Data width 64 bit
The number of CPU cores 6
The number of threads 6
Floating Point Unit Integrated (shared between each pair of cores)
Level 1 cache size ? 3 x 64 KB 2-way set associative shared instruction caches
6 x 16 KB 4-way set associative data caches
Level 2 cache size ? 3 x 2 MB 16-way set associative shared exclusive caches
Level 3 cache size 8 MB 64-way set associative shared cache
Cache latency 3 (L1 cache)
250L

mai am si alte procesoare A6,FX6100,i3,i5,i7-2100
Stare perfecta de functionare!

Nu fac schimburi!
